Model: FBP001-N

Cost-Effective Industrial Inkjet printer.

  • Brand: FAITH
  • AVAILABILITY: AVAILABLE
  • Code: MOD2952



The FBP001-N Series is a new line of continuous small character inkjet printers designed specifically for high-quality printing results and improved production line output. The FBP001-N Series features a modular design for its print heads and a sturdy stainless-steel construction for the machine body, ensuring reliable operation in harsh production environments and optimizing production line efficiency.

More reliable and professional hardware:

The motherboard adopts the American TI company AM3358 industrial-grade high-performance CPU, the American Xilinx company's Spartan7 industrial- grade high-speed computing FPGA, 256M large memory to store more information and both adopt anti-interference industrial-grade solid-state electronic components SMT manufacturing process. Various optional external interfaces such as RS232 serial port, LAN network port, USB interface, expandable input and output 10 ports, etc.

External interfaces: IP68 RS232, Network interface counter rest, information control and other functions.

Main Hardware: The main bord with newest structure has superior performance offimction and stability, and the EH'T is dustproof and water proof, better to deal with the harsh and complex environment.

Ink System: Double-head pump design makes more stable and durable. White ink machine has double mixing system to prevent the pigment in precipitation.





Details Summary:

Stainless steel body, IP68 protection level of the whole machine, more stable in various complex environments. Independent structural design of functional accessories, scientific and reasonable design, easy to repair, reduce maintenance and the usage cost. The nozzle valve is adopted to directly seal the nozzle hole structure design, which can prevent ink leakage from the nozzle after closing the ink line. It has the function of shutting down and automatically cleaning the nozzle and recovery pipe. Adding consumables is quick and easy because of the great design of ink circuit system. Simple and easy to learn, functional layout is reasonable, and easy to operate. Friendly human-computer interaction interface, what you see is what you get, real-time monitoring of printing status and content.

Key features of FAITH:


Automatic cleaning to prevent clogging.Easy operation with 10.1” large screen
Anti-counter feting traceability data printingReal-time calculation of printing costs
Wireless keyboard and mouse controlPrinting speed up to 576m/min
Print Up to 1-5 LinesPigmented & Dye-Based inks
34 DotsMachine Specifications: 400mm x 250 x 550 (length x width x height)
Ink color: Black, red, blue, green, white, invisible.Printing Content: Text, time, date, logo, dynamic barcodes/QR codes, dynamic serial date, dynamic database.
Operating Environment: Temperature 0-45 C / Humidity 30-70% RHPower parameters: Input 100-240 V AC.
Nozzle Specifications: 40u, 50u, 60u.Machine Material: 304 stainless steels
Multiple Nozzle size optionAutomatic diagnosis displayed in color text
Automatic viscosity and ink level control, Remote monitoring of printing errors, Electronics and ink system are installed separately, literally emission - free. Network capable & password protection.
Related Certifications: RoHS. CE, FDA,SGS, FCS, ISO.
